Hall Effect Sensor Kit
$ 104.50
ADD ON PRODUCTS
1/8th Mounting Boss Aluminium
$ 35.20
1/8th Mounting Boss Steel
$ 30.80
4 key (2×2) CAN Keypad with interchangeable 15mm inserts (sold separately)
Original price was: $ 526.90.$ 525.00Current price is: $ 525.00.
5m T Loom – Early Atom G4
$ 302.50
90°ANGLE UNION FOR AIR 5#
$ 21.23LOOKING FOR A SPECIFIC PART?
If you can't find it on the site, let us know, we'll check availability or source it for you.
Hall effect sensor designed for use in applications where ferrous edge detection/near zero speed sensing is needed. They provide a sinking current output.
Typical automotive applications include:
Crank & Cam Signals
Speedometers
Anti-lock braking systems
Thread = M12x1.0
Lead Length = 1m (20 AWG) Pin Out: Brown = Supply VCC Blue = Ground Black = Output V Voltage = 5v – 24v
Max Current Draw = 6 mA
Maximum Speed Detection = 15 kHz
Maximum Installation Torque Limit = 5.65 Nm (50 in lb) on thread Recommended
External Pull-Up Resistor:
5 Volts DC = 1k Ohms
9 Volts DC = 1.8k Ohms
12 Volts DC = 2.4k Ohms
15 Volts DC = 3k Ohms
24 Volts DC = 3k Ohms
Operating Supply Voltage = 5 to 24 VDC
Maximum Input Voltage = 30 VDC
Maximum Reverse Voltage = 24 VDC
Supply Current = 3 mA typ., 6 mA max
Output Sink Current = 20 mA max
Housing Material = Anodized Aluminum
Operating Temperature = -40 °C to 125 ?C
Ingress Protection = IP67
Sensor Length = 65.5mm (2.58 inches)
| Weight | 2 lbs |
|---|---|
| Dimensions | 10 × 20 × 30 in |
